LAUNCH X-431 ECU/TCU Programmer Standalone Cloning Tool w/ Checksum Correction, IMMO OFF & Anti-Theft Shutdown

PC Software Description:


Firstly, connect the X-431 ECU&TCU Programmer to the computer with a hole wire. Then, click to enter the software. The serial number will be automatically recognized from the X-431 ECU&TCU Programmer, and the activation code needs to be obtained from the envelope bar of the X-431 ECU&TCU Programmer. Click [Activate] to activate (only activate once, no need to activate again later), as shown in Figure 1. Without connection, you cannot access the software, as shown in Figure 2.





I.ECU Data Reading/Writing

1. Obtain the related ECU.

(1) Method 1: Obtain the desired ECU type through brand > model > engine > ECU in turn, as shown in Figure 3.

(2) Method 2: Query the desired ECU by entering a value in the search box. The search categories includeBosch number and Search, as shown in Figure 4. For example, search for the MED17.5.25 engine by Search, as shown in Figure 5.







2. Click [Direct Connection Diagram] to obtain the ECU connection diagram, as shown in Figure 6.





3. Connection: Connect the ECU and PCBOX according to the information provided in the connection diagram. The physical connection diagram of MED17.5.25 (using the BENCH mode line) is shown in Figure 7, and the physical connection diagram using the gearbox adapter is shown in Figure 8.





4. Read the chip ID, as shown in Figure 9.





5. Back up the EEPROM data and save it, as shown in Figure 10 (the figure shows the save page of the read data).





6. Back up the FLASH data and save it, as shown in Figure 11 (the figure shows the process of reading FLASH data).





7. Restore EEPROM/FLASH data, as shown in Figure 12 (the figure shows the file selection page).





II. Data Processing


1. Click the [Data Processing] button on the main page, as shown in Figure 13, and select [IMMO Off and File Verification] ([DTC Shield] is not currently supported), as shown in Figure 14.



2. File verification and IMMO off (process: select file > connect network to obtain > save file), as shown in Figure 15.

Package includes:



1pc x main unit

1pc x USB cable

1pc x MCU cable V1

1pc x Bench Mode Cable V2.0

6pcs x Matching adapters A

6pcs x Matching adapters B

6pcs x Matching adapters C

6pcs x Matching adapters D

6pcs x Matching adapters E

6pcs x Matching adapters F

1pc x switching power adapter

1pc x European power cord

1pc x user manual

1pc x packing list

1pc x password envelope

1pc x carrying case
